1）.“Two transmitters & one receptor” vertical bidirectional scattering technique, realizing a balanced response to different colors and smoke particles of different diameters in combination of the relative light intensity ratio algorithm, which is able to rule out interruptions caused by non-fire hazards to avoid false alarm.
2）.Self-adaptive technology, which dynamically compensates environmental change and the aging of components, keeps the stability of the sensitivity of detector and extends its lifespan.
●Electronically addressed,unique ID,log on automatically,easy for installation and commissioning.
●Embedded base, slim design, fluid shape, not easy to absorb dust.
●Fire LED allows 360° viewing
●Rotating removable lid design,easy for cleaning the maze on site; whole buckled patent structure,
easy for commissioning and maintenance.
●Water seepage prevention design.
●Patented technology for the maze realized balanced response to different color and particle smoke,
can eliminate the interference caused by non-fire factors to avoid false alarm, azimuth response
performance is superior.
●Adopts adaptive technology, it can do dynamic compensation for environmental change, aging of
components, the detector sensitivity remains stable and prolong life.
●Self-test function, real-time detection of the internal circuitry to ensure long-term stable operation
of the detector .
· Working temperature: －10℃ ～ +50 ℃
· Working humidity: ≤95% RH (No condensation of moisture)
· Working wire voltage: DC24V Pulsating voltage
· Wind speed: ＜5m/s
· Alarm indicating lamp: Red, flickers during routing inspection, keeps lighting during alarming· Protection level of casing: IP30
· Carried standard: GB 4715-2005 Spot-Type Smoke Detector
· Scattering: Bidirectional scattering
· Standby current: ＜0.35mA
· Alarming current: ＜0.8mA
· Monitoring area: 60m2
· Wiring system: Two-wire bus, non-polarized
· Bus length: ≤2000m
· Cleaning of detector: Rotatable, detachable
· Color:EI White
· PCB process: Waxdip
|
|
|
